Dayton 2H614 AC Gearmotor, 12 RPM, TEFC, 115/230V TN3P_IXF615

Product details:

Split Phase Motor Type; Needle Throughout with Thrust Balls on Case Bearings; Ball on Motor Bearings; Adaptable to 5X400 Brake; Yes Capacitor Included; USA Country of Origin; 2.1 A Current; 1.1 A Current; Die Cast Aluminum Enclosure Material; 50 Hz Frequency; 60 Hz Frequency; 700 in-lb Full-Load Torque; Die Cast Aluminum Gear Case Material; Steel Gear Material; 138:1 Gear Ratio; Helical/Spur Gear Type; 0.166667 hp Input Power; Permanent Heavy Fluid Gear Oil Lubrication; Totally Enclosed Fan-Cooled NEMA Enclosure Type; 15 RPM Maximum Speed; 0 RPM Minimum Speed; Face Mounting Location; All Angle Mounting Position; Thru-Bolt Mounting Style; 12 RPM Nameplate RPM; 900 lb Overhung Load; Single Phase; AC Power Type; Spring Loaded Lip Type on Input and Output Shaft Seals; Keyed Shaft Design; 0.75 in Shaft Diameter; 2 in Shaft Length; CW/CCW Shaft Rotation; None Thermal Protection; 115V AC Voltage; 230V AC Voltage; 11.625 in Body Length; 40 ° C Maximum Ambient Temperature
