Dayton 52Jd98 AC Gearmotor, Nameplate RPM 6.3, 1.50A GL8M_VUS808

Product details:

Here is some additional information about Dayton AC Gearmotor. Voltage: 115, Rpm Range: 0 to 15. Features - Nameplate RPM: 6.3Bearings: Sintered Bronze Sleeve - RPM Range: 0 to 15Thermal Protection: Auto - Capacitor Required: No - Length Less Shaft: 4-1/4 inch - Finish: Unpainted - Shaft Orientation: Parallel - Rotation: CWBrake: None - Number of Brake Discs Required: 0Shaft Dia. (Dimension U): 3/8 inch - Overall Length: 5-1/4 inch - Housing: Die Cast Zinc - Gears: Spur - Shaft: Single Output - Service Factor: 1.00Gear Case Material: Die Cast Zinc - Insulation Class: ALubrication: Grease filled - Hz: 60Enclosure: Open - Overhung Load: 30 lb. - Motor Shaft Design: Flat - Gear Type: Spur - Phase: 1Voltage: 115Gear Ratio: 529.2:1Full Load Amps: 1.5Max. - No Load RPM: 6.7Input HP: 1/60Gear Material: Sintered Steel - Reversible Shaft Output: No Ambient Temp.: 40 Degrees CApplication: Ice Dispensing, Mail Sorting, Ticket Dispensing, DVD Kiosks, Conveyors, Agriculture, Industrial Machinery, Printing Press, Power Transmission, Packaging, Controls, X-Ray Equipment, Pumps, Ingredient Motors, Water Softeners, Vending, Food and Restaurant Equipment, Amusement Devices, Valve Actuators, Security Systems - Shaft Length (Dimension V): 1 inch - Standards: UL Recognized/CSAMounting: All Position - Motor Type: Shaded pole
